At Honyo Prototype, we deliver mission-critical custom steel welding solutions engineered for uncompromising structural integrity and dimensional accuracy. Our expertise spans complex assemblies requiring strict adherence to ASTM, ASME, and ISO standards, leveraging TIG, MIG, and robotic welding processes for repeatability in aerospace, defense, and industrial applications. What distinguishes our approach is the seamless integration of welding with in-house CNC machining capabilities. This vertical integration ensures welded components undergo precision post-weld machining—milling, turning, and grinding—to achieve tight tolerances (±0.0005″) and flawless surface finishes, eliminating inter-vendor coordination delays and maintaining GD&T compliance from raw material to finished part.

Procurement teams accelerate project timelines through our Online Instant Quote platform, which provides validated lead times and pricing for combined welding and CNC projects within minutes. Upload CAD files to receive manufacturability feedback and cost transparency without manual RFQ bottlenecks, ensuring your steel fabrication meets both performance and schedule demands.

Service Integration	Key Benefit	Typical Application Impact
Welding + CNC Machining	Eliminates secondary operations	30% faster assembly for hydraulic manifolds
In-House Material Traceability	Full compliance documentation	Reduced audit risk in medical device frames
Digital Workflow (Quote to Delivery)	Real-time production tracking	25% shorter lead times vs. fragmented suppliers

---

Technical Capabilities

Custom steel welding in conjunction with precision machining such as 3/4/5-axis milling and turning requires a high degree of technical integration to achieve tight tolerances and superior part integrity. At Honyo Prototype, we combine advanced welding techniques with multi-axis CNC machining to deliver high-performance components for demanding applications. Below are the technical specifications relevant to our custom steel welding and precision manufacturing services.

Technical Specifications Overview

Parameter	Specification Detail
Machining Capabilities	3-axis, 4-axis, and 5-axis CNC milling; CNC turning (swiss and standard); multi-tasking machining centers
Welding Processes	TIG (GTAW), MIG (GMAW), and laser welding for steel and aluminum; qualified weld procedures (ASME, AWS D1.1)
Tolerance Range	±0.0002″ (5 µm) for critical dimensions; typical machining tolerance ±0.001″ (25 µm)
Surface Finish	As-machined: 32–64 µin Ra; polished or coated finishes available upon request
Materials Supported	Steel: Mild steel, stainless steel (304, 316, 17-4 PH), tool steel Aluminum: 6061-T6, 7075-T6, 2024-T3 Plastics: ABS (flame retardant and standard), Nylon 6, Nylon 6/6 (reinforced and unreinforced)
Maximum Work Envelope	Milling: 40″ x 20″ x 20″ (5-axis); Turning: Ø16″ x 48″ max diameter and length
Inspection & Metrology	CMM (Coordinate Measuring Machine), optical comparators, laser scanning, and in-process probing
Secondary Operations	Heat treating, anodizing (Al), passivation (stainless), powder coating, robotic deburring
Compliance Standards	ISO 9001:2015, AS9100D (aerospace), ITAR registered, NADCAP (for welding and NDT upon request)

Our integrated approach ensures that welded assemblies are machined to maintain geometric accuracy and dimensional stability. For hybrid components involving steel weldments with machined aluminum or plastic sub-assemblies, we apply thermal compensation strategies and fixture-based alignment to preserve tight tolerance requirements across dissimilar materials. This capability is ideal for aerospace, defense, and industrial automation applications where reliability and precision are critical.

---

From CAD to Part: The Process

Honyo Prototype Custom Steel Welding Process Overview
Our streamlined workflow for custom steel welding projects minimizes lead time while ensuring precision and structural integrity. The process begins with digital integration and progresses through rigorous engineering validation to final delivery, leveraging proprietary AI tools and certified welding procedures.

Upload CAD
Clients initiate the process by uploading native CAD files (STEP, IGES, or native SOLIDWORKS) via our secure customer portal. Our system automatically validates file integrity, extracts critical geometric data, and identifies key welding parameters such as joint types, material thicknesses, and weld symbols per AWS D1.1 standards. This phase ensures dimensional accuracy and prevents downstream rework caused by incomplete or corrupted data.

AI-Powered Quoting
Uploaded CAD data feeds into our proprietary AI quotation engine, which analyzes over 200 manufacturing variables including weld length density, accessibility constraints, material grade compatibility (e.g., A36, 4140, 304SS), and geometric complexity. The AI cross-references real-time shop floor capacity, material costs, and labor rates to generate a technically validated quote within 2 business hours. Unlike manual quoting, our system flags potential cost drivers such as tight tolerances in welded assemblies or excessive repositioning requirements, providing actionable insights before order commitment.

Engineering-Driven DFM Review
All quotes trigger a mandatory Design for Manufacturability (DFM) review by our ASME-certified welding engineers. This phase focuses on weld optimization: evaluating joint preparation feasibility, recommending alternative weld types (e.g., substituting groove welds with fillet welds where structurally permissible), and identifying distortion risks in complex steel assemblies. We provide a detailed DFM report with annotated CAD markups within 24 hours of quote acceptance, including weld sequence simulations for critical components to mitigate residual stress. Client collaboration is required to approve revisions before production release.

Precision Production Execution
Approved designs move to our climate-controlled welding bay equipped with FANUC robotic cells and certified TIG/MIG stations. All steel welding adheres to ISO 3834-2 quality standards with the following protocols:
Material traceability via laser-etched heat numbers
Pre-weld joint cleaning per SSPC-SP 3 standards
Real-time monitoring of heat input (J/mm) using thermal imaging
In-process weld inspections at 50% and 100% completion stages
Critical welds undergo 100% visual inspection (VT) with additional NDT (RT/UT) as specified. All welders hold AWS D1.1 structural steel certifications with quarterly requalification.

Quality-Controlled Delivery
Final assemblies undergo comprehensive dimensional verification against original CAD using FARO Arm CMM scans, with full weld quality documentation packaged in the shipment. Standard delivery includes:
Certified material test reports (MTRs)
Weld procedure specifications (WPS/PQR)
Dimensional inspection report (ASME Y14.5)
NDT certification (if applicable)
Parts ship via tracked freight with environmental protection packaging to prevent transit damage, typically within 10–15 business days after DFM approval. Rush services reduce this to 5–7 days for qualified geometries.

Process Performance Metrics
The following table summarizes key improvements enabled by our integrated workflow compared to industry averages:

Phase	Honyo Prototype	Industry Average	Improvement
Quote Turnaround	≤2 business days	5–7 business days	60–70% faster
DFM Resolution	≤24 hours	3–5 business days	80% faster
First-Pass Weld Yield	98.7%	89.2%	9.5% higher
On-Time Delivery	99.1%	92.4%	6.7% higher

This closed-loop process ensures welded steel components meet stringent structural requirements while reducing time-to-prototype by 40% versus conventional manufacturing partners. All projects include dedicated engineering support from CAD upload through delivery to resolve technical queries and ensure specification compliance.

---
