Manufacturing Insight: Cnc Router 4 Axis For Sale
Precision 4-Axis CNC Router Solutions for Demanding Manufacturing Applications
Honyo Prototype delivers advanced CNC machining capabilities engineered to meet the rigorous demands of aerospace, medical device, and precision industrial component production. Our state-of-the-art 4-axis CNC router systems excel in producing complex geometries with exceptional accuracy, reducing secondary operations through simultaneous multi-face machining. This capability translates directly to shorter lead times, minimized part handling errors, and superior surface finishes for materials ranging from aerospace-grade composites to high-density plastics and non-ferrous alloys.
As a full-service manufacturing partner, Honyo integrates this advanced 4-axis technology within our certified production ecosystem, ensuring stringent adherence to AS9100 and ISO 13485 standards. Every component undergoes rigorous in-process inspection using calibrated CMM and optical measurement systems, guaranteeing dimensional compliance within ±0.005mm tolerances. Our engineering team collaborates closely with clients to optimize part designs for manufacturability, leveraging decades of experience in high-mix, low-volume prototyping and bridge production.
For immediate project evaluation, utilize Honyo Prototype’s Online Instant Quote platform. Upload your 3D CAD files to receive a detailed manufacturability analysis and competitive pricing within 2 hours—accelerating your path from design validation to certified production.
Key Technical Specifications at a Glance
| Parameter | Specification |
|———————|———————————–|
| Axis Configuration | X, Y, Z, Rotary (A-axis) |
| Positioning Accuracy| ±0.005 mm |
| Max Work Envelope | 1200 x 2400 x 200 mm |
| Spindle Speed | 24,000 RPM (HSD ER20) |
| Material Compatibility | Composites, ABS, PEEK, Aluminum, Foam |
| Control System | Siemens 840D Solution Line |
Elevate your production capability with Honyo’s turnkey 4-axis CNC routing solutions—where engineering precision meets scalable manufacturing execution. Initiate your project with confidence through our streamlined digital quoting workflow today.
Technical Capabilities
CNC Router 4-Axis Technical Specifications
The following table outlines the key technical specifications for a high-precision 4-axis CNC router suitable for 3, 4, and 5-axis milling applications, with optional turning capability. This machine is engineered for tight-tolerance production across a range of materials including aluminum, steel, ABS, and nylon. Designed for prototyping and low-volume manufacturing, it delivers repeatability and accuracy required in aerospace, automotive, and industrial sectors.
| Specification | Details |
|---|---|
| Control System | Fanuc 31i-MODEL B or Siemens 840D (optional) |
| Number of Axes | 4-axis standard (X, Y, Z, A-rotary); compatible with 5-axis retrofit |
| Travel (X-Y-Z) | 1000 mm × 600 mm × 500 mm (39.4″ × 23.6″ × 19.7″) |
| Rotary Axis (A-axis) | 360° continuous rotation, ±0.001° indexing accuracy |
| Spindle Speed | 24,000 RPM HSK-63F tool holder, air-cooled or liquid-cooled option |
| Spindle Power | 15 kW (20 HP) servo-driven |
| Positioning Accuracy | ±0.005 mm (±0.0002″) |
| Repeatability | ±0.003 mm (±0.0001″) |
| Table Type | T-slotted cast iron or vacuum hold-down option |
| Maximum Tool Capacity | 24-tools ATC (Automatic Tool Changer) |
| Rapid Traverse (X/Y/Z) | 48 m/min (1,890 in/min) |
| Cutting Feed Rate | 1–10,000 mm/min (adjustable) |
| Positioning Tolerance | Achieves ±0.01 mm (±0.0004″) on complex geometries |
| Materials Compatible | Aluminum (6061, 7075), Mild & Stainless Steel, ABS, Nylon (PA6, PA66), Delrin, PEEK |
| Coolant System | Through-spindle coolant with mist collector |
| Tool Length Measurement | Laser or touch probe system (standard) |
| Work Envelope (Max Part Size) | Ø500 mm × 400 mm (for rotary axis integration) |
| Surface Finish Capability | <1.6 µm Ra (typical for aluminum and steel) |
| Optional Features | 5-axis swivel head, live tooling for turning, probing system, enclosure with dust extraction |
This 4-axis CNC router supports simultaneous multi-axis milling for complex contours and high-detail machining. Its rigid gantry structure and precision ball screws ensure dimensional stability during extended production runs. The machine is capable of holding tight tolerances down to ±0.01 mm, making it ideal for functional prototypes and end-use parts in engineering-grade plastics and metals. Integration with CAD/CAM software (e.g., Mastercam, Fusion 360, HyperMill) enables seamless programming for 3D toolpaths and rotary indexing operations.
From CAD to Part: The Process
Honyo Prototype provides precision 4-axis CNC routing services for rapid prototyping and low-volume production. We do not sell CNC router machines; instead, we utilize advanced 4-axis CNC routing equipment to manufacture customer-designed parts. Our streamlined process ensures technical accuracy and manufacturing efficiency from initial design to final delivery.
Upload CAD
Customers submit industry-standard CAD files (STEP, IGES, native SolidWorks, etc.) via our secure online portal. Our system validates file integrity and geometric completeness, confirming the design is suitable for 4-axis machining. Complex geometries requiring continuous 4-axis motion or indexed operations are automatically flagged for engineering review. File acceptance triggers immediate entry into our quoting pipeline.
AI-Powered Quoting Engine
Our proprietary AI engine analyzes the CAD geometry against live machine capacity, material availability, and shop floor scheduling data. The algorithm calculates precise machining time based on toolpath complexity, material removal volume, and fixture requirements specific to 4-axis operations. Within 2 hours, customers receive a detailed technical quote showing:
Itemized costs (material, machine time, finishing)
Recommended materials (e.g., aluminum 6061-T6, ABS, HDPE)
Critical process notes (e.g., “Requires tombstone fixture for 4-sided machining”)
Real-time lead time based on current production load
Engineering-Driven DFM Review
All quotes undergo mandatory Design for Manufacturability analysis by our senior manufacturing engineers. This phase identifies and resolves potential production issues before machining begins. Key focus areas include:
| DFM Factor | Common Issue Detected | Honyo Resolution Example |
|---|---|---|
| Axis Limitations | Undercuts requiring 5th axis | Redesign part orientation for 4-axis capability |
| Thin Walls | Vibration-induced deflection | Recommend minimum 0.060″ wall thickness |
| Tolerance Stackup | ±0.001″ specs on non-critical features | Propose GD&T adjustments to reduce cost |
| Fixturing | Complex vacuum requirements | Design modular tombstone setup for batch runs |
Customers receive annotated feedback with actionable suggestions within 24 hours. Approval requires explicit sign-off on any design modifications.
Precision 4-Axis Production
Approved orders move to our dedicated 4-axis CNC cell featuring Haas UMC-750 machines with 50-taper spindles and 0.0002″ positioning accuracy. Each run includes:
Material certification verification (e.g., mill test reports for metals)
First-article inspection per AS9102 format with CMM reporting
In-process checks at critical stages (e.g., after roughing and finishing passes)
Full documentation of machine parameters (RPM, feed rates, tool offsets)
All parts achieve ±0.005″ typical tolerance with surface finishes down to 63 μin Ra. Complex multi-sided features are machined in single setups to maintain dimensional integrity.
Quality-Controlled Delivery
Final inspection includes full FAI documentation and first-article reports packaged with the shipment. Parts are securely packaged with anti-corrosion protection for metals and custom foam cradles for fragile geometries. Customers receive:
Tracking number with real-time logistics visibility
Complete quality package (CMM reports, material certs, process records)
Digital delivery confirmation with photos of packaged parts
Standard lead time is 5-7 business days from DFM approval. Expedited options (3-5 days) are available for urgent requirements with priority scheduling. All shipments include our 100% quality guarantee with rapid resolution for any discrepancies.
Start Your Project
Upgrade your manufacturing capabilities with our high-performance 4-axis CNC router, engineered for precision and durability. Designed for demanding prototyping and production environments, this machine delivers exceptional accuracy across complex geometries.
Built in our Shenzhen factory, each unit undergoes rigorous quality testing to ensure reliability and long-term performance. Ideal for aerospace, automotive, and advanced fabrication applications.
For pricing and technical specifications, contact Susan Leo at [email protected]. Lead times and customization options available upon request.
