Precision CNC Machining for Medical Applications
Honyo Prototype delivers mission-critical CNC machined components engineered to meet the stringent demands of the medical device industry. Our ISO 13485-certified manufacturing processes ensure uncompromising quality, biocompatibility, and regulatory compliance for implants, surgical instruments, diagnostic equipment housings, and fluid handling systems. We specialize in tight-tolerance machining of medical-grade materials including ASTM F138 stainless steel, Ti-6Al-4V ELI titanium, PEEK, and cobalt-chrome alloys, with capabilities extending to ±0.0002″ tolerances and Ra 0.8 μin surface finishes.
End-to-End Medical Manufacturing Expertise
From rapid prototyping to low-volume production, Honyo integrates advanced 3-, 4-, and 5-axis CNC milling and turning with rigorous in-process inspection protocols. Our technical team collaborates directly with medical device developers to optimize part geometry for manufacturability while adhering to FDA QSR and MDR requirements. Secondary operations including passivation, laser marking, and precision cleaning are performed in controlled environments to maintain material integrity and sterility assurance.
Accelerate Development with Instant Quoting
Eliminate procurement delays with Honyo’s Online Instant Quote system. Upload CAD files in STEP, IGES, or Parasolid formats to receive a detailed manufacturability analysis and competitive pricing within hours—not days. This digital workflow provides transparent cost breakdowns, lead time estimates, and material recommendations specifically calibrated for medical applications, enabling faster iteration cycles and accelerated time-to-market for your next-generation devices.
| Key Medical Manufacturing Capabilities | Specifications |
|---|---|
| Material Compliance | ASTM F899, ISO 5832, USP Class VI |
| Dimensional Accuracy | ±0.0002″ (5 μm) |
| Surface Finish | Ra 0.8 μin (20 nm) achievable |
| Max Work Envelope | 20″ x 16″ x 12″ (508 x 406 x 305 mm) |
| Lead Time (Prototype) | As fast as 5 business days |
Partner with Honyo to transform complex medical designs into certified, production-ready components with engineering rigor and supply chain agility.
Technical Capabilities
Honyo Prototype delivers precision CNC machined components for medical device applications requiring high reliability, biocompatibility, and tight dimensional control. Our capabilities include 3, 4, and 5-axis milling as well as CNC turning, enabling complex geometries and critical feature accuracy. Below are the technical specifications for CNC medical parts based on process and material.
| Parameter | 3-Axis Milling | 4-Axis Milling | 5-Axis Milling | CNC Turning |
|---|---|---|---|---|
| Typical Tolerance | ±0.005 mm (±0.0002″) | ±0.005 mm (±0.0002″) | ±0.005 mm (±0.0002″) | ±0.005 mm (±0.0002″) |
| Positional Accuracy | ±0.002 mm | ±0.002 mm | ±0.001 mm | ±0.002 mm |
| Surface Finish (Typical) | Ra 0.8 – 1.6 µm | Ra 0.8 – 1.6 µm | Ra 0.4 – 1.6 µm | Ra 0.8 – 1.6 µm |
| Max Work Envelope (mm) | 500 x 400 x 300 | 500 x 400 x 300 + rotary | 450 x 400 x 350 + dual rotary | Ø300 x 500 (bar feed) |
| Feature Complexity | Moderate (2.5D) | High (angled features) | Very High (organic shapes) | Cylindrical + undercuts |
Compatible Materials for Medical CNC Parts
| Material | Machinability | Typical Applications | Notes |
|---|---|---|---|
| Aluminum 6061-T6 | Excellent | Housings, fixtures, surgical guides | Lightweight, easily anodized, biocompatible with coating |
| Stainless Steel 316L | Good | Implants, fluid connectors, instruments | High corrosion resistance, biocompatible, ASTM F138 compliant available |
| Titanium Grade 5 (Ti-6Al-4V) | Moderate | Orthopedic implants, dental components | High strength-to-density, excellent biocompatibility |
| ABS (Medical Grade) | Excellent | Prototypes, enclosures, non-implantable devices | USP Class VI compliant options, sterilizable (gamma/e-beam) |
| Nylon 6/6 or 12 (CF-reinforced) | Good | Insulating components, wear parts | High wear resistance, low friction, autoclave-resistant grades available |
All CNC medical parts are manufactured in a controlled environment with full traceability, adhering to ISO 13485 standards. First article inspection (FAI), CMM reporting, and visual inspection are standard for critical features. Tight tolerance features such as sealing surfaces, mating bores, and alignment interfaces are routinely held within ±0.0125 mm (±0.0005″) with process validation.
From CAD to Part: The Process
Honyo Prototype CNC Medical Parts Manufacturing Process Overview
Honyo Prototype delivers precision CNC medical components through a rigorously controlled workflow designed for regulatory compliance, speed, and zero-defect outcomes. Our process begins with CAD file submission and concludes with validated delivery, integrating AI-driven efficiency with stringent medical-grade quality protocols. Below is a technical breakdown of each phase.
CAD File Submission and Validation
Clients initiate the process by uploading native CAD files (STEP, IGES, Parasolid, or native SOLIDWORKS) via our secure customer portal. Our system performs automated geometry validation to verify file integrity, unit consistency, and manufacturability against baseline tolerances. Files failing validation trigger immediate client notification with specific error diagnostics, ensuring only fully compliant designs advance to quoting. This step eliminates 92% of upstream errors before engineering engagement.
AI-Powered Quoting Engine
Validated CAD data feeds into our proprietary AI quoting platform, which analyzes geometric complexity, material requirements (e.g., ISO 10993-certified PEEK, 316L stainless steel, or titanium), and tolerance stacks (including ultra-precise medical-specific GD&T callouts). The engine cross-references real-time machine capacity, material pricing, and historical production data to generate a formal quote within 2 business hours. Quotes include explicit process capability indices (Cp/Cpk ≥ 1.67 for critical features), secondary operation notes (e.g., passivation, electropolishing), and compliance documentation pathways (ISO 13485, FDA 21 CFR Part 820).
Medical-Grade DFM Analysis
Upon quote acceptance, our engineering team conducts a dual-phase Design for Manufacturability review. Phase 1 uses AI to flag high-risk geometries (e.g., thin walls <0.5mm, deep cavities with aspect ratios >10:1) against medical-specific failure modes. Phase 2 involves senior engineers performing manual DFM for regulatory alignment, focusing on:
| DFM Focus Area | Medical-Specific Checks | Risk Mitigation Example |
|---|---|---|
| Material Selection | Biocompatibility documentation traceability | Rejecting non-ASTM F138 stainless variants |
| Tolerance Allocation | Functional impact on assembly (e.g., catheter hubs) | Tightening positional tolerances by 30% |
| Surface Finish | Ra ≤ 0.8µm for implant contact zones | Recommending isotropic finishing processes |
| Cleanability | Elimination of crevices >0.1mm per FDA guidance | Redesigning undercuts to open geometries |
Client sign-off on DFM recommendations is mandatory before production, reducing iteration cycles by 70% versus industry averages.
Precision CNC Production
Approved designs enter our ISO 13485-certified cleanroom facility (Class 8 per ISO 14644-1) for machining. Key production protocols include:
Dedicated medical material lots with full mill certificates and traceability to heat/lot numbers
In-process verification via calibrated CMMs (0.0001″ accuracy) and optical comparators at defined stage gates
Real-time SPC monitoring of critical dimensions (e.g., thread pitch on bone screws) with automatic machine tool compensation
Mandatory first-article inspection per AS9102 standards, including material hardness testing and surface roughness validation
All non-conformances trigger immediate containment per our CAPA system, with root-cause analysis documented in the device history record.
Regulatory-Compliant Delivery
Final parts undergo 100% visual inspection under 10x magnification per AQL 0.65 Level II, followed by packaging in ISO 11607-compliant sterile barrier systems (where specified). Each shipment includes:
Signed Certificate of Conformance with material/test data
Complete DHR documentation package (traceable to CAD revision)
Sterilization validation reports (if applicable)
Dimensional inspection reports with actual vs. nominal values
Parts are shipped via temperature-controlled logistics with real-time GPS tracking, meeting agreed delivery windows at 99.2% reliability.
This end-to-end process ensures medical device components meet the highest safety and performance standards while accelerating time-to-market. Honyo Prototype’s integration of AI efficiency with deep medical manufacturing expertise eliminates traditional prototyping bottlenecks without compromising regulatory rigor.
Start Your Project
Looking for precision CNC medical parts manufactured to the highest industry standards? Honyo Prototype specializes in CNC machining for the medical sector, delivering tight-tolerance components with consistent quality and fast turnaround.
Our Shenzhen-based factory is equipped with advanced CNC technology and adheres to strict ISO-compliant processes, ensuring reliability for critical medical applications.
Contact Susan Leo today at [email protected] to discuss your project requirements and get a competitive quote.
