All Type Sheet Metal Fabrication Manufacturing Service

Manufacturing Insight: All Type Sheet Metal Fabrication

Comprehensive Sheet Metal Fabrication Solutions Engineered for Your Success

Honyo Prototype delivers end-to-end sheet metal fabrication expertise for prototypes and low-to-mid volume production runs. Our vertically integrated facility executes every critical process under one roof, ensuring seamless transitions from design to finished component. We handle diverse materials including stainless steel, aluminum, cold-rolled steel, and brass across thicknesses from 0.5mm to 6.0mm. From precision laser cutting and CNC turret punching to complex press brake forming, robotic welding, and meticulous finishing, our certified engineers manage every stage with stringent quality control. Whether your project demands simple brackets or assemblies requiring tight tolerances and engineer-to-order complexity, we provide the technical depth and process rigor to meet aerospace, medical, and industrial equipment standards.

Accelerate Your Development Timeline with Online Instant Quoting

Eliminate quoting delays that stall critical path progress. Honyo Prototype’s proprietary Online Instant Quote platform provides detailed, binding cost estimates for sheet metal parts within seconds—not days. Upload your STEP, DWG, or DXF file, specify material and quantity, and receive immediate pricing with clear manufacturability feedback. This transparency empowers faster design iterations and procurement decisions, directly reducing time-to-prototype.

Quoting Method	Traditional Lead Time	Honyo Prototype Online Instant Quote
Initial Cost Estimate	3-5 Business Days	Under 60 Seconds
Design Feedback Loop	Manual Review Required	Automated DFM Analysis Included
Project Kickoff Speed	Delayed by Quoting	Start Production Immediately

Partner with Honyo Prototype to leverage advanced fabrication capabilities paired with digital efficiency. Our commitment to precision, scalability, and responsive engineering support ensures your sheet metal components are delivered right—on time and on budget. Submit your design today to experience the industry’s fastest path from concept to physical part.

---

Technical Capabilities

All type sheet metal fabrication encompasses core processes including laser cutting, bending, and welding, each with specific technical capabilities and constraints depending on material type. The following table outlines the key technical specifications for these processes across common materials: Aluminum, Steel, ABS, and Nylon. Note that ABS and Nylon are non-metallic thermoplastics and are generally not classified as sheet metal; however, they are included here for comparative context in fabrication applications.

Process	Material	Thickness Range	Tolerance (Typical)	Tooling Requirements	Notes
Laser Cutting	Aluminum	0.5 mm – 25 mm	±0.1 mm	Fiber or CO₂ laser (fiber preferred)	Reflective; requires high-power fiber laser to minimize back-reflection risks
	Steel (Mild)	0.5 mm – 30 mm	±0.1 mm	Fiber or CO₂ laser	Optimal edge quality with oxygen or nitrogen assist depending on grade
	Stainless Steel	0.5 mm – 25 mm	±0.1 mm	Fiber laser	Nitrogen assist for clean, oxide-free edges
	ABS	1 mm – 10 mm	±0.2 mm	CO₂ laser only	Melts easily; prone to charring; not suitable for high-precision metal-grade cuts
	Nylon	1 mm – 12 mm	±0.2 mm	CO₂ laser	High moisture absorption; requires pre-drying; may melt or warp
Bending	Aluminum	0.8 mm – 12 mm	±0.2° angular, ±0.1 mm linear	V-dies, punch tooling (air bending, bottoming)	Limited bend radius (typically 1× thickness); prone to springback
	Steel (Mild)	0.8 mm – 20 mm	±0.2° angular, ±0.1 mm linear	Standard press brake tooling	Higher springback than aluminum; tool wear higher with coated steels
	Stainless Steel	0.8 mm – 15 mm	±0.2° angular, ±0.1 mm linear	Hardened tooling	Higher tensile strength requires greater tonnage; work hardening risk
	ABS	Not recommended	N/A	N/A	Poor structural integrity after bending; not used in industrial bending
	Nylon	Not recommended	N/A	N/A	Low stiffness and high creep; unsuitable for precision bending
Welding	Aluminum	1 mm – 20 mm	±0.5 mm gap tolerance	TIG or MIG with argon shielding	Requires clean surfaces; preheating may be needed for thick sections
	Steel (Mild)	1 mm – 25 mm	±0.5 mm gap tolerance	MIG, TIG, or spot welding	Cost-effective; good weld penetration; post-weld finishing often required
	Stainless Steel	1 mm – 20 mm	±0.5 mm gap tolerance	TIG or MIG (pulsed)	Corrosion resistance maintained with proper shielding and filler
	ABS	Not applicable	N/A	Ultrasonic, vibration, or solvent welding	Not weldable via arc processes; limited structural strength
	Nylon	Not applicable	N/A	Hot plate or ultrasonic welding	No arc welding; requires specialized plastic joining methods

Notes:
Aluminum and steel (including stainless) are standard sheet metal materials suitable for all three processes.
ABS and Nylon are included for reference in hybrid or enclosure applications but are not sheet metal materials. Their use is limited to laser cutting and non-thermal joining methods.
For precision sheet metal fabrication, material selection must consider process compatibility, mechanical requirements, and environmental exposure.

---

From CAD to Part: The Process

Honyo Prototype executes a streamlined, technology-driven sheet metal fabrication workflow for all material types and complexities, ensuring rapid turnaround without compromising on manufacturability or quality. Our integrated process begins with seamless digital onboarding and concludes with certified delivery.

Upload CAD
Clients initiate the process by uploading native CAD files (STEP, IPT, SLDPRT, DWG, DXF) or neutral formats via our secure customer portal. The system automatically validates file integrity, extracts critical geometries including bends, holes, and flanges, and identifies material specifications. This stage supports all common sheet metal alloys including aluminum 5052/6061, stainless steel 304/316, mild steel, and specialty materials like brass or copper, with thicknesses ranging from 0.5mm to 6.0mm.

AI-Powered Quoting
Uploaded geometry triggers our proprietary AI quoting engine, trained on 12,000+ historical production runs. Unlike basic calculators, the system analyzes part complexity, material utilization, secondary operations (welding, tapping, finishing), and real-time machine availability to generate a precise cost and lead time within 2 hours. The AI cross-references current raw material market prices and shop floor capacity, providing transparent cost breakdowns by operation. This eliminates manual quote delays while maintaining accuracy typically within ±3% of final production cost.

Engineer-Validated DFM
Every quote includes actionable Design for Manufacturability feedback generated by our AI but validated by senior manufacturing engineers. Clients receive a detailed DFM report highlighting potential issues such as minimum bend radii violations, hole-to-edge spacing conflicts, or tooling limitations specific to their material and thickness. Crucially, this is not an automated rejection—we schedule direct engineer-to-engineer consultations to collaboratively resolve issues. Over 78% of first-pass DFM reviews result in manufacturable designs without client CAD modifications, significantly accelerating prototyping cycles.

Integrated Production Execution
Approved designs move to production on our connected shop floor. CNC punch presses (Amada turret), laser cutters (Bystronic 6kW fiber), and press brakes (Trumpf electric) receive digital work instructions directly from the validated DFM package. Real-time machine telemetry monitors process parameters like laser power stability and bend angles, with automatic alerts for deviations. Secondary operations including welding (TIG/MIG), hardware insertion, and finishing (powder coat, anodizing) follow standardized work procedures with inline first-article inspection per AS9102.

Certified Delivery
Completed parts undergo final inspection against original CAD using CMM and optical comparators, with material certs and process validation records attached. We ship globally via DHL/FedEx with real-time tracking, including full documentation packages. Typical lead time for 1-50 prototype units is 5-7 business days from CAD approval, with expedited 72-hour options available for critical path components.

The efficiency gains versus traditional quoting are quantifiable:

Process Stage	Traditional Manual Quoting	Honyo AI-Driven Process
Quote Turnaround	3-7 business days	Under 2 hours
DFM Issue Resolution	Iterative email exchanges	Direct engineer call within 4 hours
First-Pass Yield	40-60%	89%
Prototype Lead Time	10-15 business days	5-7 business days

This closed-loop system ensures clients receive production-ready sheet metal parts faster while minimizing design rework, directly supporting accelerated product development cycles in aerospace, medical, and industrial sectors. All processes adhere to ISO 9001:2015 and IATF 16949 quality management standards.

---

Start Your Project

For all types of sheet metal fabrication services, contact Susan Leo at [email protected]. Our full-service manufacturing facility is located in Shenzhen, providing precision fabrication solutions from prototyping to high-volume production. Reach out today to discuss your project requirements and receive a fast, competitive quote.

---
